Control Panel

• Application
• Industrial Burner Automation

• Base Material
• Mild Steel

• Cabinet Material
• Powder Coated Mild Steel

• Components
• MCB, Contactor, Relay, Fuses, Indicator, Terminal Blocks

• Connectivity Type
• Wired

• Control System
• Relay Logic

• Cooling System
• Natural Air Cooling

• Cover Material
• Mild Steel

• Current Rating
• 32 A

• Dimension (L*W*H)
• 600 x 400 x 250 mm

• Display Type
• Other, LED Indications

• Features
• Easy installation, user-friendly operation, robust construction

• Frequency (MHz)
• 50 Hz

• IP Rating
• Ip54

• Material
• Other, Sheet Metal

• Maximum Output Current
• 32 A

• Operating Voltage
• 415 V AC

• Panel Type
• Floor Mounted

• Product Type
• Other, Burner Controller Panel

• Protection Class
• Class I

• Protection Level
• IP54

• Rated Current
• 32 A

• Rated Insulation Voltage
• 690 V

• Rated Operation Voltage
• 415 V

• Rated Voltage
• 415 V AC

• Standard
• IEC 61439

• Surface Color
• Other, Grey

• Surface Finish
• Powder Coated

• Thickness
• 1.6 mm

• Way
• 3 Way

• Application
• Industrial Automation, Power Distribution

• Base Material
• Other, CRCA Steel

• Cabinet Material
• Sheet Steel

• Components
• Meters, Push Buttons, Relay, Indicating Lamps

• Connectivity Type
• Wired/Optional Ethernet

• Control System
• Electromechanical/PLC based

• Cooling System
• Natural/Ventilated

• Cover Material
• Other, Tempered Glass/Steel

• Current Rating
• Up to 1600 A

• Dimension (L*W*H)
• Customizable (Standard: 1800x800x600 mm)

• Display Type
• Other, Analog/Digital

• Features
• Modular design, Rugged construction, Cable entry from top/bottom

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP42/IP54

• Material
• Other, Powder coated CRCA sheet steel

• Maximum Output Current
• 1600 A

• Operating Voltage
• 230/415 V AC

• Panel Type
• Floor Mounted

• Product Type
• Other, Free Standing Control Desk

• Protection Class
• Class I

• Protection Level
• Other, IP 42/54

• Rated Current
• Up to 2000 A

• Rated Insulation Voltage
• 660 V

• Rated Operation Voltage
• 230/415 V

• Rated Voltage
• 415 V AC

• Standard
• IS 8623, IEC 60439

• Surface Color
• Other, RAL 7032 Grey

• Surface Finish
• Other, Matte finish

• Thickness
• 1.6 mm to 2 mm

• Way
• Single/Multiple way

• Application
• Industrial Automation, HVAC, Pump Control, Process Plants

• Base Material
• Mild Steel

• Cabinet Material
• MS with Powder Coating

• Components
• Variable Frequency Drive (VFD), MCCB, MCB, Overload Relay, Contactors, Indication Lamps

• Connectivity Type
• Wired, Optional: Ethernet/Modbus

• Control System
• PLC/Relay based Control

• Cooling System
• Natural/Forced Air Cooling

• Cover Material
• Other, Mild Steel with Powder Coating

• Current Rating
• Up to 630A

• Dimension (L*W*H)
• Customized as per requirement

• Display Type
• Other, LCD/LED Indication

• Features
• Customizable Layout, Built-in Safety Interlocks, Easy Maintenance Access

• Frequency (MHz)
• 50-60 Hz

• IP Rating
• Ip54

• Material
• Other, Mild Steel (MS)

• Maximum Output Current
• 630A

• Operating Voltage
• 415V AC

• Panel Type
• Drive Control Panel

• Product Type
• Other, Customized Drive Panel

• Protection Class
• Class I

• Protection Level
• IP54

• Rated Current
• Up to 630A

• Rated Insulation Voltage
• 690V

• Rated Operation Voltage
• 415V

• Rated Voltage
• 415 V AC

• Standard
• IEC 61439 / IS 8623

• Surface Color
• Other, RAL7035 (Light Grey)

• Surface Finish
• Powder Coated

• Thickness
• 1.6 mm to 2 mm

• Way
• Multiple Ways (Custom)

• Application
• Industrial Automation, Process Control

• Base Material
• Mild Steel

• Cabinet Material
• MS Sheet Metal

• Components
• PLC, MCBs, Relays, Power Supply, Terminal Blocks

• Connectivity Type
• Ethernet, RS-485, USB

• Control System
• Programmable Logic Controller (PLC)

• Cooling System
• Natural Air Cooled

• Cover Material
• Other, Powder Coated Steel

• Current Rating
• Up to 630A

• Dimension (L*W*H)
• 1600 mm x 800 mm x 600 mm

• Display Type
• Other, LED Indication / HMI (optional)

• Features
• Dust & Moisture Proof, Corrosion Resistant, Robust Construction

• Frequency (MHz)
• 50 Hz

• IP Rating
• Ip54

• Material
• Other, Mild Steel (MS)

• Maximum Output Current
• 630A

• Operating Voltage
• 230V / 415V AC

• Panel Type
• Control Panel

• Product Type
• Other, Customized PLC Panel

• Protection Class
• Class I

• Protection Level
• IP54

• Rated Current
• 600A

• Rated Insulation Voltage
• 690V

• Rated Operation Voltage
• 440V

• Rated Voltage
• 415V AC

• Standard
• IEC/IS Standards

• Surface Color
• Other, RAL 7035 (Light Grey)

• Surface Finish
• Powder Coated

• Thickness
• 2 mm

• Way
• 3 Way

• Application
• Industrial Automation

• Base Material
• Other, Mild Steel Sheet

• Cabinet Material
• Mild Steel

• Components
• VFD, MCB, Contactor, Overload Relay, Indication Lamps

• Connectivity Type
• Terminal Block

• Control System
• Automatic/Manual

• Cooling System
• Air Ventilated

• Cover Material
• Other, Powder Coated Steel

• Current Rating
• Up to 250A

• Dimension (L*W*H)
• 1200mm x 800mm x 400mm

• Display Type
• Digital

• Features
• Corrosion Resistant, Rigid Construction, Modular Design

• Frequency (MHz)
• 50 Hz

• IP Rating
• Ip54

• Material
• Mild Steel

• Maximum Output Current
• 250A

• Operating Voltage
• 380-415V AC

• Panel Type
• Floor Mounted

• Product Type
• Other, Drive Panel

• Protection Class
• Class I

• Protection Level
• Other, IP 54

• Rated Current
• Up to 250A

• Rated Insulation Voltage
• 690V

• Rated Operation Voltage
• 415V

• Rated Voltage
• 415V AC

• Standard
• IEC 61439, IS 8623

• Surface Color
• Other, Grey

• Surface Finish
• Powder Coated

• Thickness
• 1.6 mm

• Way
• Three Phase

• Application
• Industrial Automation

• Base Material
• ABS

• Cabinet Material
• Plastic

• Components
• CPU, Touch Display, Communication Port

• Connectivity Type
• RS232, RS485, Ethernet

• Control System
• Programmable Logic Controller (PLC) Compatible

• Cooling System
• Passive Cooling

• Cover Material
• Other, Polycarbonate

• Current Rating
• 2A

• Dimension (L*W*H)
• 200 x 135 x 40 mm

• Display Type
• Other, TFT LCD

• Features
• User-Friendly Interface, Programmable Functions, Real-Time Monitoring

• Frequency (MHz)
• 50/60 Hz

• IP Rating
• Other, IP65

• Material
• Other, ABS Plastic

• Maximum Output Current
• 2A

• Operating Voltage
• 24V DC

• Panel Type
• Touch Panel

• Product Type
• Other, HMI Unit with Programming

• Protection Class
• Class II

• Protection Level
• IP65

• Rated Current
• 2A

• Rated Insulation Voltage
• 500V

• Rated Operation Voltage
• 24V DC

• Rated Voltage
• 24V DC

• Standard
• IEC 61131-2

• Surface Color
• Other, White & Grey

• Surface Finish
• Other, Matte

• Thickness
• 40 mm

• Way
• Single

• Application
• Automation & Process Control

• Base Material
• Other, MS Sheet

• Cabinet Material
• Mild Steel

• Components
• MCB, MCCB, Relays, PLC, Power Supplies

• Connectivity Type
• Ethernet, RS-485, Profibus

• Control System
• Programmable Logic Controller (PLC)

• Cooling System
• Forced Air Ventilation

• Cover Material
• Other, Powder Coated Steel

• Current Rating
• 100A - 630A

• Dimension (L*W*H)
• 1200 x 800 x 300 mm

• Display Type
• Other, Digital / MIMIC

• Features
• Modular Design, Durable Structure, Easy Wiring, Safety Interlocks

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP55

• Material
• Other, Mild Steel (MS)

• Maximum Output Current
• 630A

• Operating Voltage
• 380-440V AC

• Panel Type
• Floor Mount

• Product Type
• Other, PLC Panel

• Protection Class
• Class I

• Protection Level
• IP55

• Rated Current
• up to 630A

• Rated Insulation Voltage
• 690V

• Rated Operation Voltage
• 415V

• Rated Voltage
• 415V AC

• Standard
• IEC 61439, IS 8623

• Surface Color
• Other, Grey

• Surface Finish
• Powder Coated

• Thickness
• 1.6 mm

• Way
• 3 Way

• Application
• Industrial Automation

• Base Material
• Mild Steel

• Cabinet Material
• Mild Steel Sheet

• Components
• PLC, MCB, Contactors, Relays, Power Supply, Terminal Blocks

• Connectivity Type
• Ethernet, Serial (RS232/RS485)

• Control System
• Programmable Logic Controller (PLC)

• Cooling System
• Air Vents/Fan Cooled

• Cover Material
• Other, Tempered Glass/Sheet Metal

• Current Rating
• Up to 250 A

• Dimension (L*W*H)
• 1200 x 1000 x 400 mm

• Display Type
• Other, LED Indication

• Features
• Auto/Manual Operation, Overload Protection, Modular Construction

• Frequency (MHz)
• 50/60 Hz

• IP Rating
• Ip54

• Material
• Other, Mild Steel (MS)

• Maximum Output Current
• 250 A

• Operating Voltage
• 415 V AC

• Panel Type
• Electrical Automation Panel

• Product Type
• Other, PLC Power Panel

• Protection Class
• Class I

• Protection Level
• IP54

• Rated Current
• 125 A

• Rated Insulation Voltage
• 690 V

• Rated Operation Voltage
• 415 V

• Rated Voltage
• 415 V AC

• Standard
• IEC 61439 / IS 8623

• Surface Color
• Other, Grey

• Surface Finish
• Powder Coated

• Thickness
• 1.6 mm

• Way
• 3 Way

• Application
• Industrial Pickling Process Control

• Base Material
• Mild Steel

• Cabinet Material
• MS Sheet

• Components
• MCB, MCCB, Contactor, Overload Relay, Indication Lamps

• Connectivity Type
• Terminal / Busbar

• Control System
• PLC Based/Relay Logic

• Cooling System
• Natural / Forced Air Cooling

• Cover Material
• Other, Powder Coated Steel

• Current Rating
• 500A

• Dimension (L*W*H)
• Customizable

• Display Type
• Other, LED/Analog meters

• Features
• Long Life, Robust Build, Corrosion Resistant, User-friendly Interface

• Frequency (MHz)
• 50 Hz

• IP Rating
• Ip54

• Material
• Other, MS (Mild Steel)

• Maximum Output Current
• 500A

• Operating Voltage
• 380-415V AC

• Panel Type
• Distribution/Automation Panel

• Product Type
• Other, Pickling Line Panel

• Protection Class
• Class I

• Protection Level
• IP54

• Rated Current
• 500A

• Rated Insulation Voltage
• 690V

• Rated Operation Voltage
• 415V AC

• Rated Voltage
• 415V AC

• Standard
• IEC/IS Standard

• Surface Color
• Other, Grey

• Surface Finish
• Powder Coated

• Thickness
• 2 mm

• Way
• Multiple Way

• Application
• Industrial Motor Control, Distribution Automation

• Base Material
• Mild Steel

• Cabinet Material
• Powder Coated MS

• Components
• Air Circuit Breaker (ACB), Molded Case Circuit Breaker (MCCB), Contactors, Overload Relays, Indicating Lamps, Push Buttons

• Connectivity Type
• Cable or Bus Duct Entry

• Control System
• Manual / Automatic

• Cooling System
• Air Cooled / Natural Ventilation

• Cover Material
• Other, Mild Steel Sheet

• Current Rating
• up to 6300 Amps

• Dimension (L*W*H)
• Custom as per requirements

• Display Type
• Other, LED, Analog Meters

• Features
• Compartmentalized design, Fully segregated busbars, Arc protection, Easy maintenance

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP42 to IP65 (Optional)

• Material
• Other, Mild Steel (MS)

• Maximum Output Current
• up to 6300A

• Operating Voltage
• 415V AC

• Panel Type
• Floor Mounted, Compartmentalized

• Product Type
• Other, Motor Control Center Panel (MCC Panel)

• Protection Class
• Class I

• Protection Level
• Other, IP42 / IP54 / up to IP65

• Rated Current
• up to 6300A

• Rated Insulation Voltage
• 690V

• Rated Operation Voltage
• 415V

• Rated Voltage
• 415V AC

• Standard
• IEC 61439 / IS 8623

• Surface Color
• Other, Siemens Grey

• Surface Finish
• Powder Coated

• Thickness
• 1.6 mm / 2.0 mm (customizable)

• Way
• Multi-way
