Drive Panel

Get a Price/Quote

MOQ : 1 Unit

Drive Panel Specification

Features
Corrosion Resistant, Rigid Construction, Modular Design

Control System
Automatic/Manual

Rated Current
Up to 250A

Current Rating
Up to 250A

Base Material
Mild Steel Sheet

Protection Level
IP 54

Connectivity Type
Terminal Block

Cabinet Material
Mild Steel

Rated Insulation Voltage
690V

Cooling System
Air Ventilated

Panel Type
Floor Mounted

Way
Three Phase

Cover Material
Powder Coated Steel

Thickness
1.6 mm

Rated Operation Voltage
415V

Operating Voltage
380-415V AC

Protection Class
Class I

Components
VFD, MCB, Contactor, Overload Relay, Indication Lamps

Product Type
Drive Panel

Material
Mild Steel

Surface Finish
Powder Coated

Standard
IEC 61439, IS 8623

Surface Color
Grey

Rated Voltage
415V AC

Frequency (MHz)
50 Hz

Maximum Output Current
250A

Dimension (L*W*H)
1200mm x 800mm x 400mm

Application
Industrial Automation

IP Rating
Ip54

Display Type
Digital

Indication Lamps
R-Y-B LED Indication

Enclosure Type
Indoor

Humidity Tolerance
Up to 95% (Non-Condensing)

Operating Temperature
0C to 45C

Cable Entry
Bottom/Top Entry Options

Mounting Type
Floor Standing

Door Type
Hinged with Lock

Input Supply
3 Phase, 415V, 50Hz

Bus Bar Material
Electrolytic Grade Copper

Earthing Provision
Dual Earth Busbar

Protection Devices
MCB, MCCB Provided

Drive Panel Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Drive Panel

Jump on this exclusive clearance offer for our top-ranking Drive Panel - engineered for blue-ribbon industrial performance. Crafted from electroplated mild steel with a premium powder-coated finish, it's designed for valiant operation in challenging environments. With a robust, corrosion-resistant enclosure, IP54 protection, and modular flexibility, this drive panel delivers uncompromising safety and efficiency. Featuring dual earth busbars, digital display, hinged lockable doors, state-of-the-art VFD, and full suite of protection devices, it's the trusted solution for serious industrial automation. Ready to power up with 3-phase, 415V input and support up to 250A for your most demanding applications.

Drive Panel: Directions Of Use, Advantages & Applications

This Drive Panel is quick to set up; simply mount the floor-standing enclosure in your desired indoor location, connect via bottom or top cable entry, and activate the digital controls for either manual or automatic operations. Designed for industrial automation, it guarantees valiant reliability with outstanding operating efficiency. Its main advantages include corrosion resistance, modular build, and ease of maintenance. Suitable for manufacturing units, process plants, utilities, and automation projects, benefit from enhanced safety and streamlined control.

Packaging, Export Market & Sample Policy

Each Drive Panel is securely packed in sturdy, export-grade packaging to ensure safe delivery to your site. Delivered with care, our panels are supplied throughout India and to global markets, including Asia, Africa, and the Middle East. Rates are determined based on destination and requirements. We offer a reasonable sampling policy-enabling potential buyers to assess our build and quality before bulk orders. Our export market reputation underscores our commitment to reliable service and timely shipment.

FAQ's of Drive Panel:

Q: How do I install the Drive Panel in my facility?

A: To install the Drive Panel, position the floor-standing enclosure indoors, connect input and output cables through the bottom or top entry options, and secure the dual earth busbars. Follow the provided wiring diagram and ensure all locks and safety mechanisms are engaged before operation.

Q: What benefits does this Drive Panel provide for industrial automation?

A: This Drive Panel delivers robust protection (IP54 rated), fast setup, and modular design, making it ideal for dynamic automation needs. Its blue-ribbon components ensure valiant performance, efficient control (automatic/manual), and reliability in demanding environments.

Q: Where can the Drive Panel be used effectively?

A: It is best used in industrial settings such as factories, process plants, manufacturing units, and automation systems where dependable motor and drive control is essential.

Q: What is the process to request a sample panel?

A: Contact our sales team with your specifications. We follow a transparent sample policy-samples are provided at a nominal rate to help you evaluate the quality and features before committing to a large order.

Q: How does the Drive Panel ensure safety and protection?

A: Safety is enhanced by the inclusion of MCBs, MCCBs, dual earthing, lockable doors, and class-leading insulation, meeting IEC 61439 and IS 8623 standards. The panel offers full protection against overload, short circuits, and environmental ingress.
