DC Drive

DC Drive Specification

Cabinet Material
Mild Steel (MS)

Base Material
Mild Steel

Protection Level
IP20

Components
SCR, Fuse, Variable Potentiometer, Display

Operating Voltage
180 V to 220 V DC

Thickness
3 mm

Control System
Analog

Features
Overload Protection, Compact Design, Easy Installation, Speed Regulation

Cover Material
Powder Coated Metal

Way
Single Way

Current Rating
10 Amps

Rated Insulation Voltage
250 V

Connectivity Type
Terminal Block

Cooling System
Natural Air Cooled

Rated Current
10 A

Protection Class
Class I

Rated Operation Voltage
220 V DC

Panel Type
Enclosed

Product Type
DC Drive

Material
Metal Body with High Grade Insulation

Surface Finish
Powder Coated

Standard
IS Compatible

Surface Color
Grey

Rated Voltage
220 V

Frequency (MHz)
50 Hz

Maximum Output Current
10 A

Dimension (L*W*H)
200 mm x 120 mm x 80 mm

Application
DC Motor Speed Control

IP Rating
IP20

Display Type
Digital LED

Cable Entry
Knockout

Start/Stop Control
Soft Start

Weight
2.5 Kg

Fuse Protection
Built-in

Cooling Efficiency
High

Humidity Tolerance
up to 90% RH non-condensing

Insulation Resistance
>20 M at 500 VDC

Speed Control Range
10% - 100%

Motor Compatibility
Shunt and PMDC Motors

Input Voltage Range
180-230 V AC

Ambient Temperature Range
-10C to +50C

Mounting Type
Wall Mounting

DC Drive Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About DC Drive

Explore the unrivaled capabilities of our Special DC Drive, designed for transcendent motor control in demanding industrial environments. Highlighted by a 180-230V AC input range, this wall-mounted unit easily fits shunt and PMDC motors and excels under extreme ambient temperatures from -10C to +50C with up to 90% RH humidity tolerance. Built-in fuse protection, soft start, and a wide speed control range (10%-100%) ensure famed reliability. Its powder-coated, mild steel body ensures durability, while high-grade insulation and IP20-rated safety exemplify superior build quality for any specialized application.

DC Drive Applications & Surface Integration

This DC Drive is highlighted for plant automation, industrial line control, and machinery requiring precise DC motor speed regulation. Its robust metal enclosure with powder coating permits reliable surface mounting on machinery panels or plant walls. Favoring compact, enclosed installations, it excels in diverse surface conditions, offering overload protection, natural air cooling, and easy installation. The clear digital display and terminal block connectivity make user integration straightforward for a variety of specialized plant applications and demanding environments.

DC Drive Shipment, Certification & Export Market

Outlaying swift and secure shipment, our DC Drive generally arrives within 1-2 weeks from order confirmation. Each unit is IS compliant and fully tested to meet stringent industrial certifications. The charge includes robust packaging to ensure safety in transit. Our main export markets encompass India, Southeast Asia, and the Middle East, serving both manufacturers and service providers. Customers can expect transparent order tracking and responsive post-shipment support for all deliveries.

FAQ's of DC Drive:

Q: How does the DC Drive provide protection during operation?

A: The DC Drive features built-in fuse protection and overload safeguards, ensuring continued safety and reliability even under demanding usage. Its insulation resistance over 20 M at 500 VDC and IP20 enclosure further enhance operator and equipment safety.

Q: What types of motors are compatible with this DC Drive?

A: This drive is compatible with both shunt and Permanent Magnet DC (PMDC) motors, making it suitable for a range of industrial and plant-based applications requiring variable speed control.

Q: When should I use the soft start function of the DC Drive?

A: You should use the soft start function whenever you power up connected DC motors to prevent sudden surges, reduce mechanical stress, and prolong equipment lifespan-especially in applications involving frequent starts and stops.

Q: Where can the DC Drive be installed for optimal performance?

A: For optimal performance, the DC Drive should be mounted securely on a wall or machinery panel in environments with ambient temperatures between -10C and +50C, protected from excessive dust and non-condensing humidity up to 90% RH.

Q: What is the process for wiring and connecting the DC Drive?

A: Wiring is made simple via the terminal block connectors and knockout cable entry points. Always follow the provided wiring diagrams and ensure the system is powered off during installation to maintain safety and device integrity.

Q: How does the compact design benefit plant operators?

A: The compact, 2.5 kg design with a sealed panel makes installation easy even in space-constrained areas, while the robust construction and high-efficiency cooling ensure reliable operation and minimal maintenance for plant operators.
